Apple M1 PRO M1  MAX

Apple M1 Pro chip
8-core CPU with 6 performance cores
and 2 efficiency cores
14-core GPU
16-core Neural Engine
200GB/s memory bandwidth
Media engine
Hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW
Video decode engine
Video encode engine
ProRes encode and decode engine
Configurable to:
M1 Pro with 10-core CPU and
14-core GPU, M1 Pro with 10-core
CPU and 16-core GPU, M1 Max
with 10-core CPU and 24-core GPU, or
M1 Max with 10-core CPU and
32-core GPU
Apple M1 Pro chip
10-core CPU with 8 performance cores
and 2 efficiency cores
16-core GPU
16-core Neural Engine
200GB/s memory bandwidth
Media engine
Hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW
Video decode engine
Video encode engine
ProRes encode and decode engine
Configurable to:
M1 Max with 10-core CPU
and 24-core GPU or M1 Max with
10-core CPU and 32-core GPU



https://www.apple.com/macbook-pro-14-and-16/specs/



XDR (Extreme Dynamic Range)



Up to 1000 nits sustained (full-screen) brightness, 1600 nits peak brightness

1,000,000:1 contrast ratio



Color



1 billion colors

Wide color (P3)

True Tone technology



Refresh rates



ProMotion technology for adaptive refresh rates up to 120Hz

Fixed refresh rates: 47.95Hz, 48.00Hz, 50.00Hz, 59.94Hz, 60.00Hz



Memory

16GB

16GB unified memory

Configurable to:

32GB (M1 Pro or M1 Max) or 64GB (M1 Max)

Battery and
Power2

Up to 17 hours Apple TV app movie playback

Up to 11 hours wireless web

70-watt-hour lithium-polymer battery2

67W USB-C Power Adapter (included with M1 Pro with 8-core CPU)

96W USB-C Power Adapter (included with M1 Pro with 10-core CPU or M1 Max, configurable with M1 Pro with 8-core CPU)

USB-C to MagSafe 3 Cable

Fast-charge capable with 96W USB-C Power Adapter

Storage3

512GB

512GB SSD

Configurable to:

1TB, 2TB, 4TB, or 8TB

1TB

1TB SSD

Configurable to:

2TB, 4TB, or 8TB

Charging and Expansion

SDXC card slot

HDMI port

3.5 mm headphone jack

MagSafe 3 port

Three Thunderbolt 4 (USB-C) ports with support for:



Charging

DisplayPort

Thunderbolt 4 (up to 40Gb/s)

USB 4 (up to 40Gb/s)

SDXC Thunderbolt 4 HDMI MagSafe 3 Thunderbolt 4 Headphone jack
Video Support

Simultaneously supports full native resolution on the built-in display at 1 billion
colors and:

Up to two external displays with up to 6K resolution at 60Hz at over a billion colors (M1 Pro) or
Up to three external displays with up to 6K resolution and one external display with up to 4K resolution at 60Hz at over a billion colors (M1 Max)

Thunderbolt 4 digital video output

Native DisplayPort output over USB‑C

VGA, HDMI, DVI, and Thunderbolt 2 output supported using adapters (sold separately)

HDMI digital video output

Support for one display with up to 4K resolution at 60Hz

DVI output using HDMI to DVI Adapter (sold separately)

Keyboard and Trackpad

Backlit Magic Keyboard with:

78 (U.S.) or 79 (ISO) keys including 12 full-height function keys and 4 arrow keys
in an inverted-T arrangement

Touch ID

Ambient light sensor

Force Touch trackpad for precise cursor control and pressure-sensing
capabilities; enables Force clicks, accelerators, pressure-sensitive drawing, and
Multi-Touch gestures

Force Touch trackpad
Wireless

Wi-Fi

802.11ax Wi-Fi 6 wireless networking
IEEE 802.11a/b/g/n/ac compatible

Bluetooth

Bluetooth 5.0 wireless technology

Camera

1080p FaceTime HD camera
Advanced image signal processor with computational video

Audio

High-fidelity six-speaker sound system with force-cancelling woofers

Wide stereo sound

Support for spatial audio when playing music or video with Dolby Atmos on built-in speakers

Spatial audio with dynamic head tracking when using AirPods (3rd generation), AirPods Pro, and AirPods Max

Studio-quality three-mic array with high signal-to-noise ratio and directional beamforming

3.5 mm headphone jack with advanced support for high-impedance headphones

Operating Requirements

Line voltage: 100V to 240V AC

Frequency: 50Hz to 60Hz

Operating temperature: 50° to 95° F (10° to 35° C)

Storage temperature: –13° to 113° F (–25° to 45° C)

Relative humidity: 0% to 90% noncondensing

Operating altitude: tested up to 10,000 feet

Maximum storage altitude: 15,000 feet

Maximum shipping altitude: 35,000 feet

Size and Weight

Height 0.61 inch (1.55 cm)

Width: 12.31 inches (31.26 cm)

Depth: 8.71 inches (22.12 cm)

Weight: 3.5 pounds (1.6 kg)4
